Hive Installation - Worcester Greenstar 24I Junior

Discussion in 'Plumbing and Central Heating' started by Jag-diynot, 27 Oct 2021.

  1. Jag-diynot

    Jag-diynot

    Joined:
    27 Oct 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    Hello Everyone,
    I bought the Hive Thermostat System (Heating Only). My current boiler is Worcester Greenstar 24I Junior. The current installation has a separate mains power supply to Boiler. Picture Below

    [​IMG]

    And then there is another wire from boiler connected to Honeywell Thermostat. It’s a simple thermostat to switch the central heating on and off. I do not have any timer installed currently (inbuilt or otherwise).

    [​IMG]


    Just wondering how easy is to install the Hive thermostats with current boiler set up. Below is the Hive wiring diagram. If I am understanding it correctly, according to this dia both mains and heating on off wire connection goes into the Hive Reciever. How would the installtion for Hive work in this case?

    [​IMG]
    Thank you.
    Jag

    Last edited: 27 Oct 2021
  2. Sponsored Links
  3. EFLImpudence

    EFLImpudence

    Joined:
    7 Jul 2010
    Messages:
    37,456
    Thanks Received:
    4,203
    Location:
    Retired to:
    Country:
    Portugal
    The receiver needs power to work.

    So, you just connect L & N from the switch and the wires that go to the thermostat to 1 & 3.

    • Thanks Thanks x 1
  4. ianmcd

    ianmcd

    Joined:
    15 Aug 2010
    Messages:
    23,521
    Thanks Received:
    9,721
    Location:
    Lanarkshire
    Country:
    United Kingdom
    your pics arent showing bottom right hand corner upload a file then add your pics that way

    Last edited: 27 Oct 2021
    • Thanks Thanks x 2
  5. Jag-diynot

    Jag-diynot

    Joined:
    27 Oct 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    Thanks Ian and EFLImpudence. Ian, below is the picture I hope I have taken it correctly. The wire on left is the mains power. The wire on right goes to Honeywell Thermostat.
    [​IMG]

  6. Jag-diynot

    Jag-diynot

    Joined:
    27 Oct 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    For the thermostat to 1 & 3, which one I use for live and neutral? I guess 1 will be for neutral and 3 for live? Also, another question, Would the earth wires from both switch and thermostat go togather to "Earth Tether" ?

    Last edited: 27 Oct 2021
  7. EFLImpudence

    EFLImpudence

    Joined:
    7 Jul 2010
    Messages:
    37,456
    Thanks Received:
    4,203
    Location:
    Retired to:
    Country:
    Portugal
    They are not Live and Neutral but Live and Switched live.


    It doesn't actually matter which way round with only two but connect Brown to 1 and Blue to 3.

    As said, it doesn't actually matter with only the two but do it the other way round.

    Yes all earth wires should be connected together at each accessory.

    • Thanks Thanks x 2
