Lightswitch with just 2 red wires?

Discussion in 'Electrics UK' started by Jonathandelorean, 10 Apr 2021.

  1. Jonathandelorean

    Jonathandelorean

    Joined:
    10 Apr 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    I'm looking to swap my single lightswitch over to a dimmer, but after opening it up I see there's just 2 red wires. There is an earth which is connected to a screw in the back box but that's it.

    One of the red wires is connected to a terminal labelled "Top" and the other is connected to an unlabelled terminal.

    I was expecting to see a neutral wire as the other switches I've changed all have neutrals. The new dimmer has 3 terminals (L1, L2 and Com).

    Just wondering which way to wire this up?

  2. Sponsored Links
  3. AndyPRK

    AndyPRK

    Joined:
    4 Jan 2009
    Messages:
    5,471
    Thanks Received:
    526
    Location:
    Herefordshire
    Country:
    United Kingdom
    Use com

    And one of the L terminals.

    • Thanks Thanks x 1
  4. flameport

    flameport

    Joined:
    10 Mar 2007
    Messages:
    9,417
    Thanks Received:
    1,841
    Location:
    Poole, Dorset
    Country:
    United Kingdom
    Unlikely, switches do not generally have neutral terminals.
    Black wires are not necessarily neutral either.

    • Thanks Thanks x 1
  5. Jonathandelorean

    Jonathandelorean

    Joined:
    10 Apr 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    Aah ok I had assumed the black wires in the other switches were neutral

  6. Jonathandelorean

    Jonathandelorean

    Joined:
    10 Apr 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    That's great, thank you - does it matter which of the red wires I use in which terminal? There's no visual way of differentiating between them.

  7. EFLImpudence

    EFLImpudence

    Joined:
    7 Jul 2010
    Messages:
    35,752
    Thanks Received:
    3,997
    Location:
    Retired to:
    Country:
    Portugal
    I shall use my new graphic.


    • Thanks Thanks x 1
    • Like Like x 1
  8. AndyPRK

    AndyPRK

    Joined:
    4 Jan 2009
    Messages:
    5,471
    Thanks Received:
    526
    Location:
    Herefordshire
    Country:
    United Kingdom
    No.

    You could put Top into Com though.

    If the switch works backwards you need to use the other L terminal

    • Thanks Thanks x 1
  9. EFLImpudence

    EFLImpudence

    Joined:
    7 Jul 2010
    Messages:
    35,752
    Thanks Received:
    3,997
    Location:
    Retired to:
    Country:
    Portugal
    No, it doesn't matter.

    • Thanks Thanks x 1
  10. Sponsored Links
  11. Jonathandelorean

    Jonathandelorean

    Joined:
    10 Apr 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    Thanks for the responses folks!

  12. Sureitsoff?

    Sureitsoff?

    Joined:
    27 Jul 2007
    Messages:
    666
    Thanks Received:
    100
    Location:
    Norfolk
    Country:
    United Kingdom
    or turn the switch upside down!

  13. AndyPRK

    AndyPRK

    Joined:
    4 Jan 2009
    Messages:
    5,471
    Thanks Received:
    526
    Location:
    Herefordshire
    Country:
    United Kingdom
    It's a dimmer

    • Like Like x 1
  14. securespark

    securespark

    Joined:
    11 Jan 2004
    Messages:
    36,222
    Thanks Received:
    1,215
    Country:
    United Kingdom
    When you think about that statement, if it were true, the switch would be connecting the live wire directly to the neutral wire every time you closed it.

    What would happen then?

  15. Jonathandelorean

    Jonathandelorean

    Joined:
    10 Apr 2021
    Messages:
    5
    Thanks Received:
    0
    Country:
    United Kingdom
    Ah.. actually that's a good point... :oops:

    I've always just changed switches on autopilot and never really paused to think much about it. I feel a bit silly now!!!

  16. securespark

    securespark

    Joined:
    11 Jan 2004
    Messages:
    36,222
    Thanks Received:
    1,215
    Country:
    United Kingdom
    :)

    No need. It's a common misunderstanding.
